Search in your own words! Type what you are looking for and we will find the best matches. Which scooter folds small enough for my trunk?
  • 15.3 miRange
  • 5 mphTop speed
  • 450 lbCapacity

Avid by Merits Ultra HD Heavy Duty Power Wheelchair P331

  • AvailabilityCall to orderConfigured to order, we confirm the lead time on the call
  • BrandMerits
  • ModelP331
$4,279Was $5,349Save $1,070

May require an evaluation and special delivery.

Free shippingNo sales tax added

30 day returnsReturns and warranty

30 days from the ship date to ask for a change of mind return. A 20 percent restocking fee applies and you pay the return shipping. Damage, the wrong item and faults covered by the warranty cost you nothing.

  • Up to 3 Year Service
  • Ships from Florida
  • Free Curbside Delivery
  • White Glove Available
Ratings as of Nov 2026

Call to order

We confirm your build, price and delivery on the call

Options & Upgrades

Canopy (+$159)
Extra Light (White) (+$35)
Extra Light (Red) (+$34)
Armrest Bag (+$53)
Unbreakable Cup and Bottle Holder (+$43)
Weather Cover (+$179)
Cane Holder (+$61)
Product total
Options total
Grand total

Specifications

This chair has a weight capacity of 450 lbs and a top speed of 5 mph. It is 35 in long, 27 in wide and 42 in high.

Performance
ModelP331
Weight capacity450 lbs
DrivetrainMid wheel drive
Top speed5 mph
Range per charge (55Ah batteries)Up to 15.3 miles
Range per charge (33Ah batteries)Up to 8 miles
BatteryTwo, 55Ah 22NF AGM, 51Ah 22NF gel or 33Ah U1 AGM
MotorDual in-line 2 pole, 200W
ControllerPG VR2-A2 60A programmable
Charger6A off-board
Turning radius21"
HCPCS codeK0837
Size & Seat
Overall length35"
Overall length with footplate45"
Overall width27"
Overall height42"
Seat width18" to 24"
Seat depth16" to 20"
Backrest height21" to 23"
Backrest angleAdjustable, 90 to 110 degrees
Ground clearance2.875"
ColorsWhite, Red, Blue, Charcoal Gray
Drive wheels12" x 3"
Front and rear casters6" x 2"
Weight288 to 310 lbs

Overview

Avid by Merits Ultra HD P331 heavy duty power wheelchair in red, front three quarter view with headrest and footplate

Avid by Merits Ultra HD P331 heavy duty mid wheel drive power chair with 450 lb capacity, full front and rear suspension and a width adjustable rehab seat.

The Avid by Merits Ultra HD P331 is the heavy duty powerbase in the Avid complex rehab line from Merits Health Products. It pairs a 450 lb weight capacity with a mid wheel drive layout that turns in just 21 inches, so larger riders get true indoor maneuverability without stepping up to a wide rear wheel drive frame. The base itself measures only 27 inches across, narrow enough for standard doorways and hallway turns.

Seating is where the Ultra HD separates from consumer heavy duty chairs. The 4 post rehab seat adjusts from 18 to 24 inches in width and 16 to 20 inches in depth, the backrest reclines from 90 to 110 degrees, and the factory can build the chair with power tilt up to 50 degrees plus positioning components, trunk supports and headrest choices. That makes the P331 a chair a supplier or clinician can actually fit to the rider rather than a one size frame.

Underneath, dual in line 2 pole 200W motors drive 12 inch wheels through front and rear suspension, clearing thresholds and uneven pavement while keeping the ride settled. A pair of 22NF batteries in a tool free battery box delivers up to 15.3 miles per charge with the 55Ah AGM option. The Ultra HD carries HCPCS code K0837 for Group 2 heavy duty power wheelchairs rated 301 to 450 lb.

This chair shipped for years as the Merits Vision Ultra HD and was folded into the new Avid by Merits rehab brand with the same P331 model number, so parts, manuals and service history all carry over.

Video

Avid by Merits Ultra HD Heavy Duty Power Wheelchair P331 video

Shipping

  • A boxed scooter on a pallet at the curb, lowered from a truck
    Freecurbside delivery
  • Delivery technician in white gloves showing a customer the controls of a new power wheelchair at home
    $350white glove, set up insideHow it works
  • Check firstthen sign

Add-on, sold separately

How will you transport your Avid Ultra HD?

Both carry your power chair behind your car, SUV or van. We checked both against your power chair's weight and wheels.

Your Avid Ultra HD
  • 310 lb
  • 45 x 27 in
  • Electric hitch liftEZ-Carrier Electric Lift$2,299
    • Carries 330 lbyour Avid Ultra HD weighs 310 lb
    • 60 x 32 in platformroom to spare around its wheels
    View add-on
  • Scooter trailerScootaTrailerFrom $4,444
    • Carries 600 lbyour Avid Ultra HD weighs 310 lb
    • 66 x 35.5 in bedroom to spare around its wheels
    View add-on

For your hitch and tongue weight, ask for a Free Fit Check.

A smiling woman talking on the phone at her kitchen table

Warranty

What warranty comes with the P331?

Merits backs the P331 with a manufacturer limited warranty. The exact coverage terms for this model are listed in the Specifications tab and the product documentation. Normal wear items and damage from misuse or accidents are excluded, as with all manufacturer warranties.

If something goes wrong, reach out to us first. We can often sort out a fix over the phone or ship a replacement part. Contact us and we will help.

Warranty policy

Why HDM

Talk to a real expert1-888-233-5563

Weekdays we answer right away, or call you back ASAP if we're with another customer.

Weekends we're around, but replies can take longer.

  • We know the makers

    Direct relationships with the makers speed up warranty and technical answers.

  • We stay with you after the sale

    Phone help first, and a technician if a shipping or product issue needs one.

  • A range we would buy ourselves

    Only heavy duty models we would recommend.

How much weight can the Avid Ultra HD P331 carry?

It is rated for riders up to 450 lb on a heavy duty mid wheel drive powerbase. The 4 post rehab seat adjusts from 18 to 24 in wide and 16 to 20 in deep, so it can be set to fit a larger rider rather than forcing a one size frame.

Is the Ultra HD the same chair as the Merits Vision Ultra HD?

Yes. Merits moved the Vision Ultra HD into its Avid by Merits rehab line and now markets it as the Ultra HD. The model number is still P331, so parts, manuals and service history all carry over.

Will the Ultra HD fit through my doorways?

The base is 27 in wide with a 21 in turning radius, so it turns tightly in hallways and bathrooms. Many home doors are 28 to 30 in, which leaves little room to spare, so measure the clear opening with the door fully open. It is 35 in long, or 45 in with the footplate.

How far does the Ultra HD go on a charge?

Merits rates it for up to 15.3 miles with the two 55Ah 22NF batteries, and the flyer lists up to 8 miles with the smaller 33Ah U1 batteries. The chair takes two batteries in a tool free battery box, and a 6A off board charger refills them. Choose the larger batteries if you ride long distances.

Does the Ultra HD have power tilt?

Power seat tilt from 0 to 50 degrees is a factory option. The standard build has a manual angle adjustable backrest from 90 to 110 degrees, 21 to 23 in tall. The factory can also add positioning components, trunk supports and headrest choices.

What is the ground clearance of the Ultra HD, and can it go outdoors?

Ground clearance is 2.875 in. Dual 200W motors drive 12 in wheels through front and rear suspension, which clears thresholds and uneven pavement while keeping the ride settled. Top speed is 5 mph.

How difficult is the Ultra HD to transport in a vehicle?

At 288 to 310 lb it does not go in a car. It needs a van, a lift or a trailer. Merits includes transit tie down brackets for securing the unoccupied chair in a vehicle.

Will Medicare or insurance pay for the Ultra HD?

The P331 carries HCPCS code K0837, the Group 2 heavy duty power wheelchair code for riders rated 301 to 450 lb. Medicare covers a power wheelchair only with a doctor's order and an enrolled supplier. Heavy Duty Mobility does not hold a Medicare supplier number or bill insurance, so a purchase here is private pay.

How is my chair delivered?

Delivery to your curb is free. Check the packaging and the chair before you sign for it, and call 1-888-233-5563 if anything looks wrong.

How do I order?

Call 1-888-233-5563. We confirm the build, the price and the delivery with you and place the order on the phone.

Can you check this model before I order?

Yes. Ask for a Free Fit Check. Call, chat or email and we compare your weight, your doorways, the ground and your vehicle with the specs in the manual.

Can I talk to someone before I buy?

Yes. Call 1-888-233-5563. Weekdays: we answer right away, or call you back ASAP if we're with another customer. Weekends: we're around, but replies can take longer.
