Search in your own words! Type what you are looking for and we will find the best matches. Which scooter folds small enough for my trunk?
  • 18 miRange
  • 4 mphTop speed
  • 300 lbCapacity

Merits Vision CF Travel Front Wheel Drive Power Wheelchair - P322

  • AvailabilityStock status can change very rapidly. An item might come back in stock before we update this or might have sold out. We highly recommend you call or chat with us for a 100% stock status.
  • BrandMerits
  • ModelP322
$2,267Was $2,834Save $567

Free shippingNo sales tax added

30 day returnsReturns and warranty

30 days from the ship date to ask for a change of mind return. A 20 percent restocking fee applies and you pay the return shipping. Damage, the wrong item and faults covered by the warranty cost you nothing.

  • Up to 3 Year Service
  • Ships from Florida
  • Ships in 1 to 2 Business Days
  • Free Curbside Delivery

We’ll beat any verified price

Ratings as of Nov 2026

Options & Upgrades

Positioning backs, cushions and rehab seating are available for this chair. Call us for a price.
Canopy (+$159)
Extra Light (White) (+$35)
Extra Light (Red) (+$34)
Armrest Bag (+$53)
Unbreakable Cup and Bottle Holder (+$43)
Weather Cover (+$179)
Cane Holder (+$61)
Product total
Options total
Grand total

Specifications

This chair has a weight capacity of 300 lbs, a top speed of 4 mph and a range of up to 18 miles per charge. It is 33 in long, 24 in wide and 37 in high. It weighs 154 lbs.

Performance
Part numberP322B0M-ARMUB in red (Merits also lists P322A0M-ARMUB)
Alt part numbersP322A, P322B0M-ARMUB, P322B0M, ARMUB, P322A0M-ARMUB, P322A0M
Weight capacity300 lbs.
Drive trainFWD
Turning radius17"
Top speed4 mph
Rangeup to 18 miles
MotorDC24V / 130W
ControllerDynamic LiNX 40A
Battery size (2 required)33Ah, U1 AGM
Charger4A off-board
Max incline6°
HCPCS codeK0815 / K0816 / K0820 / K0821 / K0822 / K0823
Size & Seat
Overall length33"
Overall width24"
Overall height37"
Seat typeCaptain or Pan
Seat width16" - 20"
Seat depth16" - 20"
Backrest height18" - 20"
Seat-to-floor height16.5" - 22"
Ground clearance2.4"
Color optionCandy Apple Red
Front wheels3" anti-tippers
Drive wheels9" foam-filled
Rear wheels6" foam-filled
Weight154 lbs.
Wt of heaviest pc62.7 lbs.

Overview

Merits Vision CF P322 power wheelchair, close up of the base from the front with the footplate flipped up

The Vision CF P322 Power Wheelchair by Merits Health Products is more than just a mobility device; it's a lifeline to independence and an active lifestyle. As the proud winner of the Mobility Product Award 2021, this front-wheel drive chair delivers on both style and performance.

Key Features

  • 18" wide cushioned captain's chair
  • Adjustable headrest and recline angle of 90° to 135°
  • Detachable and adjustable armrests
  • Large flip-up aluminum footplate
  • 9" drive wheels with a 22.5" turning radius
  • Travel up to 18 miles at 4 mph
  • Intelligent regenerative electromagnetic brakes
  • Front-wheel drive for steady traction
  • Lightweight and easy to disassemble
  • Removable shroud for easy maintenance
  • Sensitive joystick with speed control dial
  • Winner of the Mobility Product Award 2021
  • Industry-leading product warranty
  • Dedicated tech support staff

Comfort and Maneuverability

Designed with you in mind, the comfortable 18" wide cushioned captain's chair is perfect for long rides. Adjust the headrest to your liking, and recline the backrest anywhere from 90° to 135°. The detachable, height and width adjustable armrests ensure a custom fit, while the large flip-up aluminum footplate adds to your convenience.

But comfort is just the start. With 9" drive wheels and a tight 22.5" turning radius, this power chair offers excellent maneuverability. Whether you're indoors or out, the Vision CF P322 will get you where you need to go, turning on a dime even in tight spaces.

Performance and Capability

The Vision CF P322 Power Wheelchair is strong and comfortable. It lets you travel as far as 18 miles at a speed of 4 miles per hour. It has smart brakes that help you stop safely, and the front-wheel drive gives you a steady ride on different types of ground.

Portability and Maintenance

This chair isn't just practical; it's also light, easy to disassemble, and transportable. The well-designed frame and removable shroud make maintenance a breeze. Pop it in the trunk of your vehicle, and reassemble quickly at your destination.

Awards and Recognitions

When you pick the Vision CF P322, you're selecting a product that has won awards. It's made by a top company, and the prizes show that you can trust it to be good and reliable.

User Guide and Accessibility

Operating the Vision CF P322 is as simple as a touch. The sensitive joystick with speed control dial makes driving effortless. The ability to easily break down and reassemble the unit makes it a favorite among those looking to stay active on the go.

Customer Support and Warranty Information

Trust in Merits Health Products extends beyond the purchase. Enjoy peace of mind with our industry-leading product warranty and dedicated tech support staff, always available to ensure the proper setup and operation of your new P322 CF Power Wheelchair.

Get the Vision CF P322 Power Wheelchair for simple and trusted rides. Great features, strong support, and built by a trusted name - Merits. Go places with ease. Move smoothly with Merits.

Video

Merits Vision CF Travel Front Wheel Drive Power Wheelchair video

Shipping

  • A boxed scooter on a pallet at the curb, lowered from a truck
    Freecurbside delivery
  • Delivery technician in white gloves showing a customer the controls of a new power wheelchair at home
    $350white glove, set up insideHow it works
  • 1 to 2 business daysleaves the warehouse
  • Check firstthen sign

Add-on, sold separately

How will you transport your Vision CF?

Both carry your power chair behind your car, SUV or van. We checked both against your power chair's weight and wheels.

Your Vision CF
  • 154 lb
  • 33 x 24 in

For your hitch and tongue weight, ask for a Free Fit Check.

Why HDM

Talk to a real expert1-888-233-5563

Weekdays we answer right away, or call you back ASAP if we're with another customer.

Weekends we're around, but replies can take longer.

  • We know the makers

    Direct relationships with the makers speed up warranty and technical answers.

  • We stay with you after the sale

    Phone help first, and a technician if a shipping or product issue needs one.

  • A range we would buy ourselves

    Only heavy duty models we would recommend.

  • Honest financing

    Pay over time with Klarna, PayPal Credit or Affirm, subject to approval. Each company shows your rate and total cost before you agree.

How does the Merits Vision CF P322 come apart for travel?

The Vision CF disassembles into pieces for car transport and goes back together at your destination. The full chair weighs 154 lb, and the heaviest piece is 62.7 lb. Check that you or a helper can lift that piece into your trunk.

How much weight can the Vision CF hold?

The Vision CF is rated for riders up to 300 lb. You can choose a captain seat or a pan seat, with seat width and depth from 16 to 20 in and seat to floor height from 16.5 to 22 in. The captain seat reclines from 90 to 135 degrees and has an adjustable headrest.

How far and how fast does the Vision CF P322 go?

The spec table rates it for up to 18 miles per charge at a top speed of 4 mph, on two 33Ah U1 AGM batteries. Rider weight, slopes and cold weather lower the real range. It charges with a 4 amp off-board charger.

What does front wheel drive do on the Merits Vision CF?

The 9 in drive wheels sit at the front, which gives steady traction and lets the chair turn in a 17 in radius. With an overall width of 24 in and length of 33 in, it suits tight hallways, bathrooms and kitchens.

Will the Vision CF fit through my doors?

At 24 in wide, the Vision CF fits most interior doorways. Some older home doors give only 28 in of clear width once the door and stops are counted, so measure the actual opening before you buy.

Can the Vision CF P322 go outdoors and up ramps?

It is rated for a 6 degree incline, so it suits gentle ramps and sidewalks rather than steep hills or rough ground. The 9 in drive wheels and 6 in rear wheels are foam filled so they cannot go flat. Ground clearance is 2.4 in, so take curbs and thresholds slowly.

How do you drive the Merits Vision CF?

It drives with a Dynamic LiNX 40 amp controller through a joystick with a speed control dial. Regenerative electromagnetic brakes hold the chair when you let go. The armrests detach and adjust in height and width, and the aluminum footplate flips up for transfers.

What HCPCS codes are listed for the Vision CF P322?

The spec sheet lists HCPCS codes K0815, K0816, K0820, K0821, K0822 and K0823 depending on setup. A code alone does not mean a plan will pay. Medicare covers a power wheelchair only when medically necessary, with a written order from your treating provider, through a Medicare enrolled supplier.

How is my chair delivered?

Delivery to your curb is free. Check the packaging and the chair before you sign for it, and call 1-888-233-5563 if anything looks wrong.

Can I pay over time?

Yes. Pay over time with Klarna, PayPal Credit or Affirm, subject to approval. Each company shows your rate and total cost before you agree. See how financing works.

Can you check this model before I order?

Yes. Ask for a Free Fit Check. Call, chat or email and we compare your weight, your doorways, the ground and your vehicle with the specs in the manual.

Can I talk to someone before I buy?

Yes. Call 1-888-233-5563. Weekdays: we answer right away, or call you back ASAP if we're with another customer. Weekends: we're around, but replies can take longer.
